GUDE Systems Expert Power Control 8041 Serie Anleitung Seite 113

Spezifikationen
Endung ".0" und spezifizieren nur einen Wert. Bei SNMP Tabellen wird das "x" durch
einen Index (1 oder größer) ersetzt, um einen Wert aus der Tabelle zu adressieren.
Name
epc8041TrapCtrl
epc8041TrapIPIndex
epc8041TrapAddr
epc8041portNumber
epc8041PortIndex
epc8041PortName
epc8041PortState
epc8041PortSw itchCount
epc8041PortStartupMode
epc8041PortStartupDelay
epc8041PortRepow erTime
epc8041PortResetDuration
epc8041Buzzer
epc8041ActivePow erChan
epc8041Pow erIndex
epc8041ChanStatus
epc8041AbsEnergyActive
epc8041Pow erActive
epc8041Current
epc8041Voltage
epc8041Frequency
epc8041Pow erFactor
epc8041Pangle
epc8041Pow erApparent
epc8041Pow erReactive
epc8041AbsEnergyReactive
epc8041AbsEnergyActiveResetta
ble
113
Expert Power Control 8041/8045
OID
Description
.85.1.1.1.1.0
0 = off 1 = Ver. 1 2 = Ver. 2c 3 = Ver. 3
.85.1.1.1.2.1.1.x
A unique value, greater than zero, for each receiver slot.
.85.1.1.1.2.1.2.x
DNS name or IP address specifying one Trap receiver slot. A port can
optionally be specified: 'name:port' An empty string disables this slot.
.85.1.3.1.1.0
The number of Relay Ports
.85.1.3.1.2.1.1.x
A unique value, greater than zero, for each Relay Port.
.85.1.3.1.2.1.2.x
A textual string containing name of a Relay Port.
.85.1.3.1.2.1.3.x
current state of a Relay Port
.85.1.3.1.2.1.4.x
The total number of sw itch actions ocurred on a Relay Port. Does not
count sw itch commands w hich w ill not sw itch the ralay state, so just
real relay sw itches are displayed here.
.85.1.3.1.2.1.5.x
set Mode of startup sequence (off, on , remember last state)
.85.1.3.1.2.1.6.x
Delay in sec for startup action
.85.1.3.1.2.1.7.x
Delay in sec for repow er port after sw itching off
.85.1.3.1.2.1.8.x
Delay in sec for turning Port on again after Reset action
.85.1.3.10.0
turn Buzzer on and off
.85.1.5.1.1.0
Number of suppported Pow er Channels.
.85.1.5.1.2.1.1.x
Index of Pow er Channel entries
.85.1.5.1.2.1.2.x
0 = data not active, 1 = data valid
.85.1.5.1.2.1.3.x
Absolute Active Energy counter.
.85.1.5.1.2.1.4.x
Active Pow er
.85.1.5.1.2.1.5.x
Actual Curent on Pow er Channel.
.85.1.5.1.2.1.6.x
Actual Voltage on Pow er Channel
.85.1.5.1.2.1.7.x
Frequency of Pow er Channel
.85.1.5.1.2.1.8.x
Pow er Factor of Channel betw een -1.0 and 1.00
.85.1.5.1.2.1.9.x
Phase Angle betw een Voltage and L Line Current betw een -180.0 and
180.0
.85.1.5.1.2.1.10.x
L Line Mean Apparent Pow er
.85.1.5.1.2.1.11.x
L Line Mean Reactive Pow er
.85.1.5.1.2.1.12.x
Absolute Reactive Energy counter.
.85.1.5.1.2.1.13.x
Type Acc.
Integer32 RW
Integer32 RO
OCTETS RW
Integer32 RO
Integer32 RO
OCTETS RW
INTEGER RW
Integer32 RO
INTEGER RW
Integer32 RW
Integer32 RW
Integer32 RW
Integer32 RW
Unsigned32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Integer32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Gauge32 RW
