GUDE Systems Expert Power Control 8041 Serie Anleitung Seite 102

Spezifikationen
Offset Sensor Field
0 Absolute Active Energy
1 Power Active
2 Voltage
3 Current
4 Frequency
5 Power Factor
6 Power Angle
7 Power Apparent
8 Power Reactive
9 Absolute Active Energy Resettable
10 Absolute Reactive Energy
11 Absolute Reactive Energy Resettable
12 Reset Time - sec. since Reset
13 Forward Active Energy
14 Forward Reactive Energy
15 Forward Active Energy Resettable
16 Forward Reactive Energy Resettable
17 Reverse Active Energy
18 Reverse Reactive Energy
19 Reverse Active Energy Resettable
20 Reverse Reactive Energy Resettable
21 Residual Current Type A
22 Neutral Current
Die Messwerte der Energie-Sensoren werden als vorzeichenbehaftete 32-Bit Integer zu-
rückgegeben. Auf der geraden Adresse sind erst die höherwertigen 16-Bit, dann folgen
auf der ungeraden Adresse die niederwertigen 16-Bit
Outlet Ports Energie Adressen (Input Register)
Die Offsets entsprechen den Offsets der Line-In Energie Adressen.
Offset Port 1
0 0x3a00
1 0x3a02
2 0x3a04
3 0x3a06
4 0x3a08
5 0x3a0a
6 0x3a0c
7 0x3a0e
8 0x3a10
9 0x3a12
10 0x3a14
11 0x3a16
12 0x3a18
13 0x3a1a
14 0x3a1c
15 0x3a1e
16 0x3a20
17 0x3a22
Expert Power Control 8041/8045
Port 2 Port 3 Port 4
0x3b20 0x3c40 0x3d60
0x3b22 0x3c42 0x3d62
0x3b24 0x3c44 0x3d64
0x3b26 0x3c46 0x3d66
0x3b28 0x3c48 0x3d68
0x3b2a 0x3c4a 0x3d6a
0x3b2c 0x3c4c 0x3d6c
0x3b2e 0x3c4e 0x3d6e
0x3b30 0x3c50 0x3d70
0x3b32 0x3c52 0x3d72
0x3b34 0x3c54 0x3d74
0x3b36 0x3c56 0x3d77
0x3b38 0x3c58 0x3d78
0x3b3a 0x3c5a 0x3d7a
0x3b3c 0x3c5c 0x3d7c
0x3b3e 0x3c5e 0x3d7e
0x3b40 0x3c60 0x3d80
0x3b42 0x3c62 0x3d82
Line 1
0x400
0x402
0x404
0x406
0x408
0x40a
0x40c
0x40e
0x410
0x412
0x414
0x416
0x418
0x41a
0x41c
0x41e
0x420
0x422
0x424
0x426
0x428
0x42a
0x42c
Port 5 Port 6
0x3e80 0x3fa0
0x3e82 0x3fa2
0x3e84 0x3fa4
0x3e86 0x3fa6
0x3e88 0x3fa8
0x3e8a 0x3faa
0x3e8c 0x3fac
0x3e8e 0x3fae
0x3e90 0x3fb0
0x3e92 0x3fb2
0x3e94 0x3fb4
0x3e96 0x3fb6
0x3e98 0x3fb8
0x3e9a 0x3fba
0x3e9c 0x3fbc
0x3e9e 0x3fbe
0x3ea0 0x3fc0
0x3ea2 0x3fc2
102
