Technical Data
Mechanical data
Degree of protection (IEC 60529)
Module enclosure
Fire resistance (UL 94)
Pollutant class
Dimensions
Indication
LED indication
Module requires maintenance
Operating state
Group error
Channel error
Function indication
Retrievable parameters
Error indication
Module status and alarms
Signal errors for each channel
Signal status bit
Wire breakage input
Short circuit input
Measuring range
Mounting / Installation
Installation conditions
Mounting type
Mounting orientation
For further technical data, see www.r-stahl.com.
6

Engineering

Failure of the devices installed in the cabinet caused by too high ambient
temperature!
Non-compliance can result in material damage.
• Install and adjust the cabinet in such a way that it is always operated within
the permissible temperature range.
• Carefully observe the "Cabinet installation guide".
You can find detailed information about project engineering in the
"Cabinet installation guide" (download from www.r-stahl.com,
Product documentation, subitem "Engineering").
218149 / 948260310010
2018-07-03·BA00·III·en·02
IP20
polyamide 6GF
V2
corresponds to G3
L = 128 mm, W = 96.5 mm, H = 67 mm
"M/S" LED, blue
"RUN" LED, green
"ERR" LED, red
LED red for each channel
Manufacturer, Type, hardware revision, software revision,
serial number
• Internal bus error primer / redundant
• No response from IOM
• Configuration does not correspond to the module
• Hardware error
• Excess temperature
• Slot error
• Module requires maintenance
"0" = signal interference present; "1" = signal valid
Resistance temperature detector / resistance transmitter:
> 100 Ω; thermocouples / mV-sensors: > 1000 Ω
Resistance temperature detector / resistance transmitter: < 15 Ω
Exceeding / shortfall
On 35 mm DIN rail NS 35/15 (DIN EN 60715)
horizontal or vertical (observe operating instructions)
NOTICE
Temperature Input Module Zone 1
Series 9482/32
