Wiring
2. Spindle Wiring
Open the connector, connect the spindle red positive cable to the red positive cable, and connect the spindle black negative cable
to the black red negative cable, as shown in the figure.
Red Positive Black-red
Pole Cable Negative Pole Cable
Connector
Red Positive Pole Cable from Spindle
Black Negative Pole Cable from Spindle
20
