4. Screw the connection piece (A) into the hole.
If the plastic flange does not have a hole, proceed as follows:
1. Dismount the plastic flange.
2. Drill a vertical hole Ø 10 mm through the plastic flange.
3. Remount the plastic flange.
4. Push the weight (C) and the hose (B) through the hole.
5. Screw the connection piece (A) into the hole.
